Multi Spring Seals AMS28

PDF PDF

CHARACTERISTICS:

• Balanced.
• System attached to the shaft by allen screws.
• Not dependent on the rotation direction.
• External mounting.

OPERATING LIMITS

d1= 25 to 175 mm
p= 15 kg/cm²
v= 2 m/s
t= -20 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

It can be used in vertical agitators with moderate speeds without the need to apply auxiliary lubrication systems. Adapted to DEBRIS cleaning systems
