Single Cartridge Seals - ASC85

PDF PDF

CHARACTERISTICS:

• Balanced.
• Welded metal bellows.
• Not dependent on the rotation direction.

OPERATING LIMITS:

d,= 24 to 95 mm
p= 20 kg/cm²
v= 25 m/s
t= -40 to +200°C (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Double cartridge in which the contact surfaces are lu- bricated by an external, non-pressurised fluid (quench) or a pressurised fluid (barrier fluid). For clean or slightly contaminated and sticky fluids with fibres or large solid particles.
