Multi Spring Seals AMS27

PDF PDF

CHARACTERISTICS:

• Balanced.
• System attached to the shaft by allen screws.
• Not dependent on the rotation direction
• External mounting

OPERATING LIMITS -

d1= 25 to 160 mm
p= Vacuum 6 kg/cm²
v= 2 m/s
t= -20 to +150ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used.The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

A multi-spring mechanical seal recommended for vertical stirrers with moderate speeds. The fixed part may have cooling/lubrication systems: flush and/or cooled flange connection
