Bellows Seals - PNL

PDF PDF

CHARACTERISTICS:

• Unbalanced.
• Single Cylindrical Spring
• Not dependent on the rotation direction.

OPERATING LIMITS -
d1=8 to 40 mm
p= 12kg/cm²
v= 10 m/s
t= -20 to + 120ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Mechanical seal with a simple design for general use.
