Bellows Seals - AMB84

PDF PDF

CHARACTERISTICS:

• Balanced.
• Spiral-wound metal bellows.
• Not dependent on the rotation direction

OPERATING LIMITS -

d1 = 18 to 100 mm
p= 20 kg/cm²
v= 25 m/s
t= -40 to +200ºC (*)

(*) The temperature resistance depends on the material of the secondary seals used. The operating limits are defined by the PV factor which is determined for the sealing system characteristics and those of the application.

Description

Balanced by the bellows, without the need for a stepped shaft (models AWS10B, AMS20B). Suitable for working in applications with high pressures. The O-ring resting on the shaft does not cause wear as there is no axial movement (changes in pressure). Recommended for working with sticky or viscous fluids that require cleaning processes (CIP) or sterilisation processes (SIP) in situ due to the geometry of the spiral-wound bellows.
